Driveline
High torque: the output torque can reach 7000Nm, especially meeting the needs of pure electric vehicles
Lightweight: extreme lightweight design to meet the lightweight needs of pure electric light vehicles
| 265 axle product parameters | |
| Model | Fawde 265 axle |
| input torque（Nm） | 7000Nm |
| Rated axle load（Kg） | 3500 |
| Ratio range | 4.875-5.125 |
| Brake specification（mm） | barometric pressure320x100 hydraulic320x85 |
| B10 service life (10,000 kilometers) | 80 |
| wheelbase（mm） | 1480 |
| Axle housing section（mm） | 96x96x6 |
Reliable performance:
High torque: the output torque can reach 7000Nm, especially meeting the needs of pure electric vehicles
Lightweight: extreme lightweight design to meet the lightweight needs of pure electric light vehicles
Reliability: according to the verification standard of 500,000 kilometers
Braking: wide-body brakes and variable-section friction plates, more wear-resistant and low maintenance costs.
Various configurations:
Axle load: 3.5T axle load configuration
Torque: adapt to the torque demand below 7000Nm
Maintenance-free wheel ends: SKF maintenance-free wheel ends can be selected
Disc brake: optional disc brake
