Driveline
High torque and light weight
Various configurations to meet the needs of the whole vehicle
| 295 bridge product parameters | ||
| model | 295 axle common type | 295 axle reinforced |
| input torque（Nm） | 10000 | |
| Rated axle load（Kg） | 4000 | 5000 |
| Ratio range | 4.3-5.125 | |
| Brake specification（mm） | 320x100 | 320x130 |
| B10 service life (10,000 kilometers) | 50 | |
| wheelbase（mm） | 1565/1740 | 1678/1740 |
| Axle housing section（mm） | 106x106x6 | 110x110x6 |
High torque and light weight
High torque: the output torque can reach 10000Nm
Lightweight: the ultimate lightweight design, the demand for 521 blue car
Reliability: 500,000 km standard verification, longer reliability life
Braking: wide-body brake and variable-section friction plate, more wear-resistant and low maintenance cost
Various configurations to meet the needs of the whole vehicle
Axle load: 4T and 5T axle load configuration
Torque: adapt to the torque demand of 7000-10000Nm
Maintenance-free wheel ends: optional SKF maintenance-free wheel ends
Disc brake: optional disc brake
Disc brake: Disc brake can be optional
