Higher injection pressure, higher atomization rate, and more sufficient in combustion;
Reinforcement design on motion friction pair, structure components and other pieces, explosion pressure is high;
Initially use four-valve technology at home, with high inlet and exhaust efficiency;
Model | CA6DL2-33E3 | CA6DL2-35E3 | CA6DL2-37E3 | CA6DL2-33U | CA6DL2-35U |
Type | 6-cylinder in-line, direct injection, turbocharged&intercooling, common rail | 6-cylinder in-line, direct injection, turbocharged&intercooling, electronic unit pump | |||
Bore×Stroke (mm) | 112 × 145 | ||||
Valves/cylinder | 4 | ||||
Displacement (L) | 8.57 | ||||
Rated power (kW) | 249 | 261 | 279 | 249 | 261 |
Net power (kW) | 246 | 258 | 276 | 246 | 258 |
Rated speed (r/min) | 2100 | ||||
Maximum torque (Nm) | 1350 | 1500 | 1500 | 1350 | 1450 |
Maximum torque speed (r/min) | 1300~1500 | ||||
Fuel consumption (g/kW·h) | 192 | 194 | |||
Noise dB(A) | ≤ 96 | ||||
Technical Route | common rail | electronic unit pump | |||
Emission Compliant (TAS) | EURO Ⅲ | ||||
Net Mass (kg) | 840 | ||||
Length×Width×Height (mm) | 1285×820×1160 |
Fuel Efficient:
Higher injection pressure, higher atomization rate, and more sufficient in combustion;
Reinforcement design on motion friction pair, structure components and other pieces, explosion pressure is high;
Initially use four-valve technology at home, with high inlet and exhaust efficiency;
Optional integrate VCU device (polymorphic switch and etc.) that is researched and developed independently, and oil supply can be adjusted according to vehicle load;
Reliable:
Use inter Euro first-class brand products for the key spare parts such as piston, piston ring, crank, bearing bush and high strength bolt;
Products have passed through German TUV inter Euro certification;
Whole set B10 life span is 800,000 km.
Comfortable:
Adopt Holland LMS vibration test system to make vibration testing optimization on the whole set, providing NVH support optimization for forming a complete set, with small vibration and low noise;
Adopt helical gear transmission to improve transmission stability and reduce mechanical noise;
Adopt ladder frame to increase structure rigidity of the whole set and reduce vibration;
Optional cruise function, reduce driving strength;
Precise dynamic calibration makes the whole vehicle smooth in shifting;
Optional fuel level switch, automatically remind of drain through primary filter.
Safe:
Optional engine braking technology, with great braking power, and it is safer for going downward along a slope with heavy load;
It is optional to install OBD fault detection for real-time fault alert.
Environment-friendly:
Pass through European Union Emission Certification;
Adopt four-valve overhead camshaft technology and electric-controlled high pressure common-rail technology, with low smoke;
Emission margin is large, with emission upgrade potential.
Optimization of whole set:
Adopt Austria AVL vehicle power transmission system simulation software to calculate, analyze & compare, test and evaluate for the whole vehicle matching, and the whole vehicle has powerful matching and better economical efficiency;
Personal Design:
Optional GPS system, with vehicle management, real-time control, vehicle security, remote diagnosis and other functions;
Optional PTO device, to meet the need of special vehicle use;
Optional remote throttle, speed limits, deputy shutdown, CAN instrument and other functions.
