6DN Generating Set Engine

Share:

Rated speed: 1500rpm

Engine modelCA6DN1J-45DCA6DN1-45D
Type6-cylinder 4-stroke
Air intake typeTurbocharged& intercooling
Cooling modeWater cooling
Governor modeElectronECU
Bore×Stroke(mm)131×155
Compression ratio18∶1
Rated speed(rpm)1500
Displacement(L)12.53
Rated power(without fan)(kW)332
Standby power(without fan)(kW)365
Fuel consumption(g/kWh)195191
Oil consumption(L/h)0.06
Steady state speed regulation(%)≤3≤1
Oil capacity including filter(L)42
Emission compliantStageⅡEuroⅢ
The flywheel shell interfaceSAE1
Flywheel for 14″flexible coupling
Dry weight of base(kg)1230
Dry weight of Gen Pac(kg)1495
Overall dimension(G.P)(mm)2300×1120×1580
Fan consumption(kW)11
27℃ air consumption(m3/min)22.7
Heat rejection of exhaust(kW)240
Exhaust gas temperature after turbine(℃)470
Exhaust gas flow(m3/min)64.5
Heat rejection from engine(kW)20
Heat rejection of coolant(kW)149
Base configurationStandard configuration(add on the base)
Engine with fanIntake and exhaust sysytem: Air filter and connecting pipes; Connecting flang of exhaust pipe
Alternator 75A 28VCooling system: Radiator; Connecting pipes; Fan guard; Belt guard
Starter motor 7.5KW 24VExtendable base frame; Manual oil drain pump


Rated speed: 1800rpm

Engine modelCA6DM2-42DCA6DN1-46DCA6DM2J-42DCA6DN1J-46D
Type6-cylinder 4-strock
Air intake typeTurbocharged &  intercooling
Cooling modeWater cooling
Governor modeECUElectronic
Bore×Stroke(mm)123×155131×155123×155131×155
Compression ratio18:1
Rated speed(rpm)1800
Displacement(L)11.0512.5311.0512.53
Rated power(without fan)(kW)305338305338
Standby power(without fan)(kW)336369336369
Fuel consumption(g/kWh)189195
Oil consumption(L/h)0.06
Steady state speed regulation(%)≤1≤3
Oil capacity including filter(L)38
Emission compliantEuroⅢStageⅡ
The flywheel shell interfaceSAE1
Flywheel for 14″flexible coupling
Dry weight of base(kg)1050123010501230
Dry weight of Gen Pac(kg)1435149514351495
Fan consumption(kW)12
Base configurationStandard configuration(add on the base)
Engine with fanIntake and exhaust sysytem: Air filter and connecting pipes; Connecting flang of exhaust pipe
Alternator 75A 28VCooling system: Radiator; Connecting pipes; Fan guard; Belt guard
Starter motor 7.5kW 24VExtendable base frame; Manual oil drain pump
